Automatic Casting Machine, Brass Faucets Low Pressure Die Casting
Machine
The most important production procedure is casting. We provide
heavy-gravity and CNC automatic Low-pressure die-casting machines
to customers based on their actual production demands.
For LPDC, we have 2 models, with 1 manipulator and 2 manipulators.
Compared with the gravity pressure casting machine, the highlight
is: that complex and uniquely designed castings are available.
Advantages:
1. High-quality casting and high-precision repeatability, automated
casting with servo motor driving, linear guiding rail system;
2. High capacity ranges 400~450 castings per shift (8hrs);
3. Quick die change flange, 5 mins by manually ;
4. Furnace heating method: gas burner is standard and electricity
for option;
5. Max. die diemension 550*400mm;
6. The whole set machine is cooled by cooling water for efficient
cooling, which highly improves inductor service life;
7. Zinc Oxide dust cleaning unit for furnace cleaning;
8. Industrial PC control with Ethernet cables, die casting programs
up to 200 saved, recording & tracking furnace temperature;
9 . Cost-efficient production ( reduced melting loss, multiple die,
one-man operation, increased yield);
10. Humanization of the workstation (ergonomic design of the
workstation, minimizing heat, noise and danger of accident)
Machine Layout
Technical Parameters:
| Code | Item | Model: LPDC0201 |
| 1 | External Size: L*W*H (mm) | 6000*6000*3400 |
| 2 | Power Rate (KW) | 180 |
| 3 | Operating Voltage (V) | 380 |
| 4 | Qty. of Manipulator (sets) | 2 |
| 5 | Max. Die Mould Weight (KG) | 180 |
| 6 | Max. Die Mould Dimensions(mm) | 550*400*250 |
| 7 | Power of Electric Furnace(KW) | 2*80 |
| 8 | Furnace Melting Capacity (kg/hr) | 520 |
| 9 | Qty. of Furnace (set) | 1 |
| 10 | Qty. of Mould Cleaning Bin (set) | 1 |
| 11 | Qty. of Feeder (sets) | 2 |
| 12 | Qty. of Grahite Bath (set) | 2 |
| 13 | Qty. of Crane (set) | 1 |
| 14 | Max. Loading of Crane (KG) | 500 |
| 15 | Qty. of Tube (pieces) | 3 |
| 16 | Gas Pressure (KG) | 6 |
| 17 | Water Pressure(KG) | 3 |
| 18 | Max.Temp. of Furnace (℃) | 1250 |
| 19 | Temp.of Cooling Water(℃) | 20±2 |
| 20 | Max. Speed of Manipulator | 35° / Sec. |
| 21 | Max. Clamping Stroke of Mould (mm) | 370 |
| 22 | Angle Range of Mould Soaking (°) | 0~90 |
| 23 | Pressure of Thimble (KG) | 540 |
| 24 | Stroke of Thimble (mm) | 50 |
| 25 | Pressure of Casting (Bar) | 50~1200 |
